鎖定按鈕開關使用電源標誌

原名
Latching Pushbutton Switch With Power Logo

貨號
311050007

分類
Accessories for Prototyping

特價
200

暫無庫存

SeeedStudio 目前暫時無庫存,因為該公司無法提供確切恢復供貨時間,為了避免延宕或出貨爭議,恕不提供下單代訂服務。

資料來源:https://www.seeedstudio.com/Latching-Pushbutton-Switch-With-Power-Logo-p-1409.html

Description



The latching push button with power logo and red LED inside. It's lightweight and the design is full of technology feeling, easy to used and the usability is powerful. Searching for a nice button switch? It is exactly what you want!


Features
  • Build-in LED

  • High quality

  • Long operating life

  • Latching operation type


Specifications
  • Max. Voltage: 250VAC/5A

  • LED Max. Voltage: 24V

  • Contact Resistance: ≤50MΩ

  • Insulation Resistance: ≥100MΩ

  • Operating Temperature: -25℃ to +55℃

  • Operating Humidity: 45 to 85%RH

  • Life: 500,000 cycles+

  • Electrical Life: 50,000 cycles+

  • Solder Heat Resistance: 230℃(no more than 3 second)


Documents

Technical Details

Dimensions 50mm x 80mm x 26mm
Weight G.W 11g
Battery Exclude

Part List

Latching Pushbutton Switch With Power Logo 1

帶電源的標誌和紅色的鎖定按鈕內的LED。它的重量輕,設計充滿科技感,易於使用,實用性強大。搜索一個很好的按鈕開關?正是你想要的!
特徵
  • 內建LED
  • 高質量
  • 使用壽命長
  • 鎖定操作類型
產品規格
  • 最大。電壓:250VAC / 5A
  • LED最大。電壓:24V
  • 接觸電阻:≤50MΩ
  • 絕緣電阻:≥100MΩ
  • 工作溫度:-25℃〜+ 55℃
  • 工作濕度:45〜85%RH
  • 使用壽命:50萬次+
  • 電氣壽命:50,000次+
  • 焊料耐熱性:230℃(不超過3秒)
